The machine is designed according to the national standard GMP can finish a sequence of work: measuring, bag, filling, sealing, sewing, deliver and other processes. And widely used for food, medicine, building materials, plastic, chemical and other industries packaging powder materials. Such as milk powder, rice noodles, cereals, coffee, sugar, coffee, glutamate, solid beverage, glucose, solid, pharmaceutical, pesticide, granular additive. The main parts of machine is made by 304 stainless steel. With the famous brand of the machine body, motor, cylinder, electrical accessories, pneumatic components, pneumatic sealing machine, sewing machine. And the customer could choose the brand by himself.
Whatsapp: +86 17730044196 Richard Shen
Whatsapp: +86 15079278912 Nicole Wang
Whatsapp: +86 16621316139 Jack Wang
Manufacture Factory One: No.11 Yechang Road, Yexie Town, Songjiang District, Shanghai, China.
Manufacture Factory Two: Intersection of Longchi road and Hongqi Road, centralized demonstration park,Jin'an District, Lu'an City, China.
Descriptive abstract
The machine is designed according to the national standard GMP can finish a sequence of work.With the famous brand of the machine body, motor, cylinder, electrical accessories, pneumatic components, pneumatic sealing machine, sewing machine. And the customer could choose the brand by himself.
Main fertures
1.Designed according to the national standard GMR up to hygiem standard of foodstuff.
2.The parts which contact with the filling are made of 304 stainles: steel, suit for Anti-corrosion chemical products packing.
3. Adopts PLC-touch screen control system, with error correction, deviation alarm and other functions.
4.Adopt the new type weighing system in packing, with high speed and high precision measurement instrument, strong function.
5.With the Roller and PVC conveying belt (the skeleton is made of stainless steel) to deliver the products. Double screw feeder .The roller can be taken down to clean, easy to clean, cleaning with no dead angle.
Main Technical Data
| Model | JC-1C1-K |
| Measurement | Weighing type |
| Feeding Way | Valve Vibration Feeder |
| Packaging Weight | 5-50G |
| Packaging Accuracy | ≤±0.2％ |
| Packing Speed | ≤3bags/min |
| Air Pressure | 0.5-0.8Mpa |
| Gas Consumption | 50L/min |
| Total Power | 3.9KW |
| Power supply | 3P AC208-415V 50/60Hz |
| Weight | 400kg |
| Dimension | 4300×1300×2500mm |
